Guard Tour Control

Key Features
• Supports Smart Card (Mifare) Reader
• Real-time clock (RTC) with independent backup battery
• Compact size and Light weight
• Rugged ABS case for extensive use
• Low power consumption and long battery life
• Easy to set up checkpoints, events, route and patrolling plan
• Generate multiple patrolling reports
• Graphical layout of respectable area can be managed through software

Overview

  • Supports Smart Card (Mifare) Reader
  • Real-time clock (RTC) with independent backup battery
  • Compact size and Light weight
  • Rugged ABS case for extensive use
  • Low power consumption and long battery life
  • Easy to set up checkpoints, events, route and patrolling plan
  • Generate multiple patrolling reports
  • Graphical layout of respectable area can be managed through software

Specifications -- Guard Toor Control

Particulars Technical Specifications
  SGT60 Series
Reader Mifare
Read Range Upto 7 cms
No. Of Guards 500
Check Points (Stations) 50 per routes
No. of Routes 255
Event Buffers 1000
Communications Port RS232 / USB (factory settable)
Baud Rate 9600bps
Display Multi color LEDs
No. of Keys

Two Keys
1. Power ON/OFF
2.  Device Reset

Software Smart-I Guard Tour Software (Model No. SGT10-PT)
Color Jet Black (may change)
Rechargeable Battery YES
Battery Specs Lithium  Ion 7.4V 2.2 Amp per Hour
Battery Indication

100% to 70% battery: Green LED ON
70 % to 40 % battery: Amber LED ON
40 % to 10 % battery: Red LED ON

             10 % & below ' NO LED with Beep after 10 sec.
Batter charger 9V 750mA
