Elevator Control

Key Features
•Elevator Access Control systems allows users to access to designated floors. Elevator access can depend on the user’s classification, the time zone, which elevator is being approached, and the armed state of a floor. In addition, changes to the status of a zone can either cause elevator to grant access to a floor, or cause the elevator to deny access. By using one or more of these attributes, you can create elevator access control policies that are extremely flexible and secure. By using an elevator access control system, you can separate the general public and unauthorized users from the authorized users.
•Spectra’s Attolo series Elevator Access Controller (EAC) caters to this requirement of Elevator Access Control.
• Easy to install and configure.
• Embedded network interface for easy connectivity.
• Industry standard weigand input facilitates to connect with any readers.
• Cost saving.

Overview

  • Per elevator car one Elevator Access Controller (EAC) is must. There is no communication between two distinct elevator cars and only one card reader can be interfaced, which will be inside the elevator
  • An EAC supports 12 floors including ground floor and a basement floor. It can be attached to Elevator Access Control Expansion Board (EACEB) using FRC connector which supports additional 10 floors. Each EAC can be attached to maximum 4 EACEB to control a total of 52 floors using 1 EAC and 4 EACEB with the option of floor control relay from the EAC being directly interface with the elevators floor control buttons.
  • The elevator floor buttons are used for programming the user cards in stand alone mode. The programming mode is protected by a master card. On showing it one can add, edit or delete a user card. While adding or editing, one can select floors where the user is allowed.
  • On power failure of EAC elevator car works in normal mode in which anyone can move to any floor.
  • Leveraging on the merits of IP based system; it can easily be hooked up on the existing TCP/IP network. Thus the data can be transferred instantaneously in real time mode to a centralized server.
  • Facility to onsite upgrade the firmware over Ethernet interface so that any customization or new version can be easily upgraded without any need of removing the device.

Specifications -- Elevator Control

Specifications: Hardware

No. of Floors up to 52 maximum
No. of Floors on board 12
No. of Floors on expansion board 10
Max. Expansion boards per controller 4
Controller 1 per elevator car
CPU 8 bit Microcontroller running @ 42 MHz
Program Memory 512 Kbytes
Data Memory 2 MB Flash
Database 30,000 card holder capacity
Transactions 55,000 Timestamped transaction storage capacity
RTC Non volatile Real Time Clock Calendar
Communication 10 Base-T RJ-45 Ethernet interface (TCP/IP) with LED indication status
Reader Interface Weigand configurable from 26 bits to 40 bits / Clock data, 1 Reader port
Reader Control LED, Buzzer Control and Reader Tamper switch input
Relay interface up to 52 Relay outputs floor selection / 3A @ 12 V DC
Digital Input 2 General purpose optically isolated Digital inputs
Digital Output 1 General purpose relay output
Supply 12 V DC
Operating Temperature 0 to 49 C ( 32 F to 120 F )
Dimensions 18.0 cm ( L) x 12.4 cm (W) x 2.0 cm (D)

Specifications: Firmware

Time Zone 30 User Defined Time Zones
Access Groups 90 Access Groups
Day Access Day of the week access
Week Off Groups 30 week off groups
Holiday Groups 10 Holidays groups, 30 Holidays per group
Key Features
• smartXS is a TCP/IP based intelligent network controller.TCP/IP is the key of technology these days. Risk per door is lowest in TCP/IP based controller because there is no dependability on other controller.
• It’s a industries versatile controller which is compatible with any standard wiegand reader.
• The processing speed of the controller is very fast; as controller is equipped with industry’s fastest processor – 32 bit RISC ARM Processor.
• smartXS has 2 types of controller 2 Door controller and 4 Door controllers.
• Stores 10,000 Cards and 30,000 Event/transaction buffers.
• Fire inputs which enables all the doors to be opened up in case of Emergency
• Intrusion Inputs which enables all the door to be closed in case of Intrusion.
• Field Upgradable – Flash memory for easy firmware upgrade through existing LAN network.
• Advance access control features like Anti-passback, Facility Code, Time Zones, Emergency card, intrusion card, occupancy control, and Delay time between 2 consecutive swipe are available.

Overview

  • smartXS is a TCP/IP based intelligent network controller.TCP/IP is the key of technology these days. Risk per door is lowest in TCP/IP based controller because there is no dependability on other controller.
  • It’s a industries versatile controller which is compatible with any standard wiegand reader
  • The processing speed of the controller is very fast; as controller is equipped with industry’s fastest processor – 32 bit RISC ARM Processor
  • smartXS has 2 types of controller 2 Door controller and 4 Door controllers.
  • Stores 10,000 Cards and 30,000 Event/transaction buffers
  • Fire inputs which enables all the doors to be opened up in case of Emergency
  • Intrusion Inputs which enables all the door to be closed in case of Intrusion
  • Field Upgradable – Flash memory for easy firmware upgrade through existing LAN network
  • Advance access control features like Anti-passback, Facility Code, Time Zones, Emergency card, intrusion card, occupancy control, and Delay time between 2 consecutive swipe are available

Specification - smartELEVATOR (SEV20-X & SEV10-SV)

Particulars Technical Specifications
  SMN230 Series SMN430 Series
System Features
Memory 4 MB
Door Control 2 4
Number of Readers 2 4
Control Relay Output 2 4
Event Buffers 30,000
Number of Users 10,000
Reader Interface 26/32/34/35 Wiegand
Input Points 1 Fire Input
LCD YES
Keypad 12 Key Numeric
Inputs/Outputs 2 I/p (Door Status, Egress),    2 O/p (DOTL, Lock) 4 I/p (Door Status, Egress), 4 O/p (DOTL,Lock)
Communication ports TCP/IP
TCP/IP
Controller ID Up to 128
Controller No. Upto 9,999
Baud rate 9600bps(Default)
Power Supply 12V DC:2A max 12VDC: 5A Max
Color Siemens Grey
Battery Backup Power In-built
Supply
Biometrics Connectivity Yes (Wiegand)
Approvals CE
Access Control Features
Facility Code Available
Time Zones / Access Levels 63 + 1 (Free Time Zone)/Unlimited
Anti – Passback Hard, Soft, Area wise, Escort, User wise
Holiday Setting 42
Time Zone Slots 4 slots per day
