Sensors and Communications

Key Features
• Compatible with control panels that communicate using the Contact ID format
• Uses HSPA (3G) network for high-speed, reliable and low-cost communications to Sur-Gard I/II/III/IV receivers
• Automatically switches to 2G (EDGE/GPRS) if 3G service is not available
• 4 on-board outputs (open collector)
• Activation and initialization via automated telephone activation system (VRU), mobile interface or web-user interface provided by C24 Communications
• 4 on-board inputs
• Full event reporting
• Monitors the panel’s attempts to communicate to determine if cellular backup communications are necessary
• UL/ULC Listed
• Antenna Extension Kits available: GS-15ANT, GS-25ANT, GS-50ANT
• SIM card (included)

Overview

Specifications --

Download

Key Features
• Compatible with control panels that communicate using the Contact ID format
• Uses HSPA (3G) network for high-speed, reliable and low-cost communications to Sur-Gard I/II/III/IV receivers
• Automatically switches to 2G (EDGE/GPRS) if 3G service is not available
• 4 on-board inputs
• Activation and initialization via automated telephone activation system (VRU), mobile interface or web-user interface provided by C24 Communications
• CSFM Approved
• Includes UL listed power supply, transformer and 7 Ah rechargeable battery
• UL 864 9th Edition
• Can be used as sole or multiple path communicator
• 97 second supervisory heartbeat
• 300 second supervision windows
• Antenna Extension Kits available: GS-15ANT, GS-25ANT, GS-50ANT
• 4 on-board outputs (open collector)
• SIM card (included)
• Full event reporting
• Monitors the panel’s attempts to communicate to determine if cellular backup communications are necessary
• Compliant with NFPA72 Editions: 2002, 2007, 2010

Overview

Specification -

Download

Key Features
• Commercial fire ethernet IP communicator
• Works with any control panel that communicates using contact ID format
• Configured for standalone commercial fire applications
• Compliant with NFPA72 Editions: 2002, 2007, 2010
• Power supply included
• Compatible with most control panels that use the Contact ID format
• 128-bit AES encryption (NIST approved)
• Supports DHCP (dynamic IP addresses)
• Low network bandwidth requirements
• Reports events to 2 different receiver IP addresses
• UL standard & encrypted line security
• 4 on-board programmable zone inputs and 2 programmable voltage outputs as standalone module
• Programmable through the PK5500 LCD keypad or T-Link Console software
• Software upgrades via network
• Compatible with Sur-Gard System I/II/III/IV monitoring station receivers

Overview

Specification -

Download

Key Features
• Compatible with PC1864/1832/1616 control panels (v4.1 and higher)
• Back up and primary HSPA alarm communication
• Panel remote uploading/downloading support via HSPA
• Supervision heartbeats via HSPA
• 128-bit AES encryption via HSPA
• Full event reporting
• SIA protocol
• SIM Card (included)
• Remote activating and programming through C24 Communications
• Compatible with Sur-Gard System I/II/III/IV monitoring station receivers
• UL standard & encrypted line security
• Antenna Extension Kits available: GS-15ANTQ, GS-25ANTQ, GS-50ANTQ
• Signal strength and trouble display
• Contact ID protocol (with PowerSeries firmware v4.5 and communicator v1.1 or higher)
• PC-Link connection
• RS-422 interface for connection of the C24-HUB
• Direct connection to C24 Interactive via cellular
• Approval Listings: FCC/IC, PTCRB, UL/ULC, NIST (AES Encryption Validation), CSFM, AT&T/Rogers

Overview

Specification -

Download

Key Features
• Compatible with PC1864/1832/1616 control panels (v4.1 and higher)
• Fully redundant Internet and HSPA dual-path alarm communication
• Integrated call routing
• Panel remote uploading/downloading support via HSPA and Internet
• Supervision heartbeats via HSPA and Internet
• 128-bit AES encryption via HSPA and Internet
• Full event reporting
• SIA protocol
• SIM Card (included)
• Remote activating and programming through C24 Communications
• Compatible with Sur-Gard System I/II/III/IV monitoring station receivers
• UL standard & encrypted line security
• ULC passive or active line security levels
• Active GS account is required to use IP function
• Antenna Extension Kits available: GS-15ANTQ, GS-25ANTQ, GS-50ANTQ
• Signal strength and trouble display
• Contact ID protocol (with PowerSeries firmware v4.5 and communicator v1.1 or higher)
• PC-Link connection
• RS-422 interface for connection of the C24-HUB
• Direct connection to C24 Interactive via cellular
• Approval Listings: FCC/IC, PTCRB, UL/ULC, NIST (AES Encryption Validation), CSFM, AT&T/Rogers

Overview

Specification -

Download

Key Features
• Activation via 1 large, easy-to-use button
• Integrated LED to indicate signal transmission
• Neck strap and multifunction belt clip included
• Reliable 433 MHz technology
• Water resistant
• Full 2-second delay on panic button
• Long-life lithium batteries included
• Supervised

Overview

Specification -

Download

Key Features
• Durable, scratch-resistant buttons
• 4 programmable function keys
• Long-life lithium batteries included
• Full 3-second delay on panic alarm to reduce false alarms
• Multifunction belt clip included
• Reliable 433 MHz technology
• Optional generic rubber insert included
• Water resistant

Overview

Specification -

Download

Key Features
• Built-in reed switch
• Normally closed external contact input
• 1 lithium battery included
• Available in brown housing
• Case and wall tamper

Overview

Specification -

Download

Key Features
• WS4904P replaces the WLS904PL-433
• Based on the Bravo® 3D hardwire motion detector
• High-traffic shutdown
• WS4904P features pet immunity up to 60 lb (27 kg)
• 1 lithium battery included

Overview

Specification -

Download

Key Features
• 2-button, 3-function wireless key
• Activation via 2 large, scratch-resistant buttons
• Full 3-second delay on panic function
• Integrated LED to indicate signal transmission
• Reliable 433 MHz technology
• Long-life lithium batteries included
• Water resistant

Overview

Specification -

Download
