Dome Camera

Key Features
• 1/3” DIS
• 600 TVL resolution
• Day / night auto switch
• 3-axis adjustment
• Compact design

Overview

  • 1/3” DIS
  • 600 TVL resolution
  • Day / night auto switch
  • 3-axis adjustment
  • Compact design

Specifications -- DS-2CE5582P

Camera
Image Sensor:  1/3” DIS
Signal System:  PAL/NTSC
Effective Pixels:  720(H)×480(V)
Min. Illumination:  0.1 Lux @ (F1.2, AGC ON)
0.28 Lux @ (F2.0, AGC ON)
Shutter Time:  1/25(1/30) s to 1/15,000 s
Lens:  3.6 mm @ F2.0 (6 mm optional)
Angle of view: 70.6° (3.6 mm)
Lens Mount:  M12
Adjustment Range:  Pan: 0 - 355°, Tilt: 0 - 90°, Rotation: 0 - 355°
Day& Night:  Electronic
Horizontal Resolution:  600TVL
Synchronization:  Internal Synchronization
Video Output:  1Vp-p Composite Output (75Ω/BNC)
S/N Ratio:  More than 52dB
General
Operating Conditions:  -40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply:  12 V DC±10%
Power Consumption:  Max.1 W
Dimension:  Φ 97.8 x 64.4 mm ( Φ 3.85” x 2.54”)
Weight:  300 g (0.66 lbs)
Key Features
• 1/3" High Quality Image Sensor
• 600 TVL High Resolution Camera
• 0.01 lux @ F1.2
• 3.6 mm Fixed Lens
• CE, FCC and RoHS Certified
• AGC, AWB and BLC

Overview

  • 1/3" High Quality Image Sensor
  • 600 TVL High Resolution Camera
  • 0.01 lux @ F1.2
  • 3.6 mm Fixed Lens
  • CE, FCC and RoHS Certified
  • AGC, AWB and BLC

Specification - CP-RAC-DC60

  • Image Sensor
    1/3" High Quality Image Sensor
  • Pixels
    PAL:762(H)x504(V)
  • Resolution
    600 TVL
  • Min. Illumination
    0.01 lux @F1.2
  • S/N Ratio
    more than 52dB
  • Electronic Shutter
    PAL:1/50~1/100,000 sec
  • Flickerless Mode
    Yes
  • Lens
    3.6mm
  • Gamma Correction
    0.45 ( AGC OFF )
  • White Balance (AWB)
    Auto
  • Gain Control (AGC)
    Auto
  • Back Light Compensation
    Auto
  • Sync
    Internal
  • Video Output
    1.0Vp-p / 75 ohm
  • Power Supply
    DC12V, <40mA
  • Power Consumption
    2W
  • Dimensions
    Φ98x67H mm
  • Weight
    210g
  • Operating Temperature
    -10C ~ 50C, 14°F ~ 122°F
  • Certifications
    CE, FCC & RoHs
Key Features
• 1/4" DIS
• 500 TVL resolution
• 20m IR range
• Low illumination
• True day / night
• 3-axis adjustment

Overview

  • 1/4" DIS
  • 500 TVL resolution
  • 20m IR range
  • Low illumination
  • True day / night
  • 3-axis adjustment

Specification - DS-2CC5132P(N)-IRP

Camera
Image Sensor:  1/4'' DIS
Signal System:  PAL/NTSC
Effective Pixels:  640(H)x480(V)
Min. Illumination:  0.1 lux@F1.2, AGC on, 0 lux with IR
0.2 lux@F1.8, AGC on, 0 lux with IR
Shutter Time:  1/25(1/30) s to 1/15,000 s
Lens:  2.8mm @F1.8 (6mm, 3.6mm optional)
Angle of view: 66.2° (2.8mm)
Lens Mount:  M12
Day& Night:  IR cut filter with auto switch
Horizontal Resolution:  500 TVL
Synchronization:  Internal Synchronization
Video Output:  1Vp-p Composite Output (75Ω/BNC)
S/N Ratio:  More than 52dB
General
Operating Conditions:  -40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply:  12 V DC±10%
Power Consumption:  1W (2.5W max with IR cut fi lter on)
IR Range:  Approx 10 to 20 meters
Dimension:  Φ 89.5 × 69.8mm (Φ 3.52” × 2.75”)
Weight:  200g (0.44 lbs)
Key Features
• High Quality Image Sensor
• 600 TVL High Resolution Camera
• 0.01 lux @ F1.2
• 4-9 mm Vari-Focal Lens
• AGC, AWB and BLC
• CE, FCC and RoHS Certified

Overview

  • High Quality Image Sensor
  • 600 TVL High Resolution Camera
  • 0.01 lux @ F1.2
  • 4-9 mm Vari-Focal Lens
  • AGC, AWB and BLC
  • CE, FCC and RoHS Certified

Specification - CP-QAC-DC60VF

  • Image Sensor
    High Quality Image Sensor
  • Pixels
    PAL:752H×582V NTSC:768H×494V
  • Resolution
    600 TVL
  • Min. Illumination
    0.01 lux @F1.2
  • S/N Ratio
    more than 50dB
  • Electronic Shutter
    1/50(60)-1/100,000sec
  • Flickerless Mode
    Electrical
  • Iris Control
    Manual
  • Lens
    4-9 mm Vari-Focal Lens
  • Gamma Correction
    0.45
  • White Balance (AWB)
    Auto
  • Gain Control (AGC)
    Auto
  • Back Light Compensation
    Auto
  • Sync
    Internal Sync
  • Power Supply
    DC 12V ± 5%
  • Power Consumption
    DC12V,250mA
  • Dimensions
    120mm(w)x70mm(h)
  • Weight
    230g
  • Operating Temperature
    -10~ +50℃ RH95% Max
  • Certifications
    CE, FCC, RoHs
Key Features
• 1/3" High Quality Image Sensor
• 650 TVL High Resolution Camera
• 0.1 lux @ F1.2
• 3.6 mm Fixed Lens
• AGC, AWB and BLC
• CE, FCC and RoHS Certified

Overview

  • 1/3" High Quality Image Sensor
  • 650 TVL High Resolution Camera
  • 0.1 lux @ F1.2
  • 3.6 mm Fixed Lens
  • AGC, AWB and BLC
  • CE, FCC and RoHS Certified

Specification - CP-GAC-DC65

  • Image Sensor
    1/3" High Quality Image Sensor
  • Resolution
    650 TVL
  • Min. Illumination
    0.1 lux @F1.2
  • S/N Ratio
    more than 52db
  • Electronic Shutter
    1/50(1/60)-1/100000s
  • Lens
    3.6 mm
  • Gamma Correction
    0.45
  • White Balance (AWB)
    Auto
  • Gain Control (AGC)
    Auto
  • Back Light Compensation
    Auto
  • Sync
    Internal
  • Power Supply
    DC12V
  • Power Consumption
    0.4W
  • Dimensions
    114X114X81mm
  • Weight
    0.2KG
  • Operating Temperature
    -10~50 °C
  • Certifications
    CE, FCC, RoHs
Key Features
• 1 / 3" Sony  Super HAD II Hi Sensitive CCD
• 700 TVL Super High Resolution  Camera
• 0.01 lux @ F1.2
• 3.6 mm Fixed Lens
• AGC, AES, BLC, Mirror,  Privacy Masking and Motion Detection
• D-WDR, 2D-DNR
• CE, FCC and RoHS Certified

Overview

  • 1 / 3" Sony Super HAD II Hi Sensitive CCD
  • 700 TVL Super High Resolution Camera
  • 0.01 lux @ F1.2
  • 3.6 mm Fixed Lens
  • AGC, AES, BLC, Mirror, Privacy Masking and Motion Detection
  • D-WDR, 2D-DNR
  • CE, FCC and RoHS Certified

Specification - CP-EAC-DY70M-E

  • Image Sensor
    1/3" Sony Super HAD II Hi-sensitive CCD & DSP
  • Pixels
    PAL:960Hx582V, NTSC:967Hx494V
  • Resolution
    700 TVL
  • Min. Illumination
    0.01 lux@F1.2
  • S/N Ratio
    more than 50dB
  • Electronic Shutter
    1/50(1/60) - 1/100000 Sec
  • Lens
    3.6 mm
  • Gamma Correction
    0.45
  • White Balance (AWB)
    ON/OFF Selectable
  • Gain Control (AGC)
    ON/OFF Selectable
  • Back Light Compensation
    ON/OFF Selectable
  • Sync
    Internal
  • Video Output
    1.0 Vp-p/75 ohm
  • Special Functions
    OSD, Camera Title, Mirror, Privacy Masking=8, Motion Detection=4, D-WDR, 2D-DNR
  • Power Supply
    DC 12V ± 5%
  • Power Consumption
    <3W
  • Dimensions
    100mm x 65mm
  • Weight
    300g
  • Operating Temperature
    -20~50 °C
  • Certifications
    CE, FCC, RoHs
Key Features
• 1 / 3" Sony Super HAD II Hi Sensitive CCD
• 700 TVL Super High Resolution Camera
• 0.01 lux @ F1.2
• 4~9 mm Vari-Focal Auto Iris Lens
• AGC, AES, BLC, Mirror, Privacy Masking and Motion Detection
• D-WDR, 2D-DNR
• CE, FCC and RoHS Certified

Overview

  • 1 / 3" Sony Super HAD II Hi Sensitive CCD
  • 700 TVL Super High Resolution Camera
  • 0.01 lux @ F1.2
  • 4~9 mm Vari-Focal Auto Iris Lens
  • AGC, AES, BLC, Mirror, Privacy Masking and Motion Detection
  • D-WDR, 2D-DNR
  • CE, FCC and RoHS Certified

Specification - CP-EAC-DY70MVFH3-E

  • Image Sensor
    1 / 3" Sony Super HAD II Hi-sensitive CCD & DSP
  • Pixels
    PAL:960Hx582V, NTSC:967Hx494V
  • Resolution
    700 TVL
  • Min. Illumination
    0.01 lux @F1.2
  • S/N Ratio
    more than 50dB
  • Electronic Shutter
    1/50(1/60) - 1/100000 Sec
  • Iris Control
    Auto
  • Lens
    4~9 mm
  • Focus Mode
    Auto Iris
  • Gamma Correction
    0.45
  • White Balance (AWB)
    ON/OFF Selectable
  • Gain Control (AGC)
    ON/OFF Selectable
  • Back Light Compensation
    ON/OFF Selectable
  • Sync
    Internal
  • Video Output
    1.0 Vp-p/75 ohm
  • Special Functions
    OSD, Camera Title, Mirror, Privacy Masking=8, Motion Detection=4, D-WDR, 2D-DNR
  • Power Supply
    DC 12V ± 5%
  • Power Consumption
    <3W
  • Dimensions
    100mm x 150mm
  • Weight
    350g
  • Operating Temperature
    -20~50 °C
  • Certifications
    CE, FCC, RoHs
Key Features
• 1/3" Sony Super HAD II
• 700 TVL High Resolution Camera
• 0.01 lux @ F1.2
• 4~9 mm Vari-Focal Auto Iris Lens
• AGC, AES, BLC, HLC, Mirror, Privacy Masking and Motion Detection
• Sens Up, WDR, 2D-DNR, 3D-DNR, LSC, DIS and Eclipse
• CE, FCC and RoHS Certified

Overview

  • 1/3" Sony Super HAD II
  • 700 TVL High Resolution Camera
  • 0.01 lux @ F1.2
  • 4~9 mm Vari-Focal Auto Iris Lens
  • AGC, AES, BLC, HLC, Mirror, Privacy Masking and Motion Detection
  • Sens Up, WDR, 2D-DNR, 3D-DNR, LSC, DIS and Eclipse
  • CE, FCC and RoHS Certified

Specification - CP-EAC-DY70MVFW

  • Image Sensor
    1/3" Sony Super HAD II CCD
  • Pixels
    PAL:752Hx582V, NTSC:768Hx494V
  • Resolution
    700 TVL
  • Min. Illumination
    0.01 lux@F1.2
  • S/N Ratio
    more than 48dB
  • Electronic Shutter
    1/50(1/60) - 1/100000 Sec
  • Flickerless Mode
    ON/OFF
  • Iris Control
    Video/DC/Manual
  • Digital Zoom
    3x
  • Lens
    4~9 mm Vari-Focal Auto Iris Lens
  • Focus Mode
    Auto Iris
  • Gamma Correction
    0.45
  • White Balance (AWB)
    Auto
  • Gain Control (AGC)
    Auto
  • Back Light Compensation
    ON/OFF Selectable
  • High Light Compensation
    Yes
  • Day & Night (ICR)
    Yes
  • WDR
    Yes
  • Sync
    Internal/External Line Lock
  • Video Output
    1.0 Vp-p/75 ohm
  • Special Functions
    OSD, Camera ID, Camera Title, Mirror, Privacy Masking=7, Motion Detection=4, Sens-Up(Low Shutter)=x256, 2D-DNR, 3D-DNR, LSC, DIS, ECLIPSE
  • Power Supply
    DC 12V ± 5%
  • Power Consumption
    <4W
  • Dimensions
    100 x 150mm
  • Weight
    400g
  • Operating Temperature
    -10~50 °C
  • Certifications
    CE, FCC, RoHs
Key Features
• 1/3'' Sony ExView HAD II CCD
• Effio-E DSP
• 700 TVL Dome Camera
• 3.6 mm Fixed Lens
• Min. Illumination : 0.05Lux / F1.2
• S/w WDR, OSD Control, 12 VDC

Overview

  • 1/3'' Sony ExView HAD II CCD
  • Effio-E DSP
  • 700 TVL Dome Camera
  • 3.6 mm Fixed Lens
  • Min. Illumination : 0.05Lux / F1.2
  • S/w WDR, OSD Control, 12 VDC

Specification - CTCCD700E3

Camera
Image Sensor:  1/3'' Sony ExView HAD II CCD
Signal System:  PAL/NTSC
Effective Pixels:  NTSC:510(H) x 492(V); PAL:500(H) x 582 (V)
Min. Illumination:  0.05 Lux / F1.2
Shutter Time:  NTSC:1/60 ~ 1/100,000 sec, PAL:1/50 ~ 1/100,000 sec
Lens:  Fixed board lens 3.6mm
Lens Mount:  M12
Adjustment Range:  Pan: 0 ~ 355°, tilt: 0 ~ 90°, rotation: 0 ~ 355°
Day& Night:  0.1 Lux / F1.2
Horizontal Resolution:   700 TVL Dome Camera
Synchronization:  Internal Synchronization
Video Output:  1.0Vp-p (75 ohm, Composite)
S/N Ratio:  > 48dB
General
Operating Conditions:  -10 ~ +50, RH 95% Max
Power Supply:  12 V DC±10%
Power Consumption:  Max. 2 W
Dimension:  128(dia) x 91(H) mm
Weight:  260g

Download

Key Features
• 1/3'' Sony Super HAD II
• CCD Effio-E DSP
• 600 TVL Dome Camera
• 3.6 mm Fixed Lens
• Min. Illumination : 0.1Lux / F1.2, DC 12 V

Overview

  • 1/3'' Sony Super HAD II
  • CCD Effio-E DSP
  • 600 TVL Dome Camera
  • 3.6 mm Fixed Lens
  • Min. Illumination : 0.1Lux / F1.2, DC 12 V

Specification - CTCCD600E3

Camera
Image Sensor:  1/3'' Sony Super HAD II CCD
Signal System:  PAL/NTSC
Effective Pixels:  NTSC:510(H) x 492(V); PAL:500(H) x 582 (V)
Min. Illumination:  0.1 Lux / F1.2
Shutter Time:  NTSC:1/60 ~ 1/100,000 sec, PAL:1/50 ~ 1/100,000 sec
Lens:  Fixed board lens 3.6mm
Lens Mount:  M12
Adjustment Range:  Pan: 0 ~ 355°, tilt: 0 ~ 90°, rotation: 0 ~ 355°
Day& Night:  0.1 Lux / F1.2
Horizontal Resolution:  600TVL
Synchronization:  Internal Synchronization
Video Output:  1.0Vp-p (75 ohm, Composite)
S/N Ratio:  > 48dB
General
Operating Conditions:  -10 ~ +50, RH 95% Max
Power Supply:  12 V DC±10%
Power Consumption:  Max. 2 W
Dimension:  128(dia) x 91(H) mm
Weight:  260g

Download
